VELLEMAN SPEAKER PROTECTION CIRCUIT KIT

VELLEMAN SPEAKER PROTECTION CIRCUIT KIT
Brand: Velleman

Buy New: $15.95




Shipping Weight (lbs): 1

MPN: K4701B
EAN: 5410329047016

Availability: Usually ships in 1-2 business days

Features:
  • Rated for 300 watt speaker handling!
  • Input voltage 90 VDC
  •

Editorial Reviews:

Product Description
Burn out of a power amplifiers output stage nearly always results in a dangerous direct current to the loudspeaker terminals. In turn, this results in loudspeaker burn out. This protection circuit, requiring no power supply, is simply mounted between the amplifier and loudspeaker. When DC appears, the circuit disconnects the loudspeaker. Perfect for car stereo applications. Maximum input voltage: 90VDC, maximum current: 10A.
